Analog Dry Tone and Versatile I/O

While the RV-6’s reverb effects are high-tech digital, you can rest assured that your straight guitar tone always remains pure analog as the effect is blended in. Convenient auto-switching jacks let you integrate with any pedal chain, with support for mono, mono-to-stereo, and stereo-to-stereo operation. And by plugging into the B input only, the RV-6 outputs a 100-percent wet sound, great for working with more complex rigs that employ parallel processing chains and mixers. There’s also a jack for connecting an optional expression pedal, allowing you to control the effect level in real time as you play.

Reverb Modes

+DELAY—This is reverb combined with delay. The synergistic effect provides rich reverberation.

SHIMMER—This reverb is distinctive for its sparkling high-frequency range. It produces fantasy-like reverberation wrapped in spacious overtones.

DYNAMIC—This reverb automatically sets the depth of the effect according to your performance. It produces deep reverberation without blurring the overall shape of your playing.

ROOM—This reverb simulates the reverberation of a room. It produces warm reverberation.

HALL—This reverb simulates the reverberation of a hall. It produces clear and spacious reverberation.

PLATE—This simulates a plate reverb (a reverb unit that uses the vibration of a metal plate). It produces metallic-sounding reverberation with an extended high-frequency range.

SPRING—This simulates a spring reverb built into a guitar amp.

MODULATE—This reverb adds modulation to hall reverb, producing extremely good-feeling reverberation.

Specifications

Reverb Modes

8 modes
HALL
PLATE
ROOM
SPRING
MODULATE
+DELAY
SHIMMER
DYNAMIC

Nominal Input Level

-20 dBu

Input Impedance

1 M ohm

Nominal Output Level

-20 dBu

Output Impedance

1 k ohm

Recommended Load Impedance

10 k ohms or greater

Controls

Pedal switch
E.LEVEL knob
TONE knob
TIME knob
MODE knob

Indicator

CHECK indicator (Serves also as battery check indicator)

Connectors

INPUT-A (MONO) jack
INPUT-B jack
OUTPUT-A (MONO) jack
OUTPUT-B jack
EXP jack
AC adaptor jack (DC 9 V)

Power Supply

Alkaline battery (9V, 6LR61)
AC adaptor (sold separately)

Current Draw

95 mA

Expected battery life under continuous use
(These figures will vary depending on the actual conditions of use.)

Alkaline: Approx. 3 hours

Accessories

Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTE," and "Information")
Alkaline battery (9V, 6LR61)

Options (sold separately)

AC adaptor: PSA series
Expression Pedal: BOSS FV-500H, FV-500L, Roland EV-5

Size and Weight

Width

73 mm
2-7/8 inches

Depth

129 mm
5-1/8 inches

Height

59 mm
2-3/8 inches

Weight (including battery)

450 g
1 lb
